C Post & Z Post Machine

C Post & Z Post Machine

C Post & Z Post: Profile shields motorists from post edges and provides sectional strength when driving in difficult ground conditions. An Ezy-Carriage is used to secure the W-Beam rails to the C Post & Z Posts eliminating the requirement for blocking pieces and rail stiffening plates. This unique connection provides a softened impact for the occupants, as well as vehicle containment and redirection.

Type of material to be processed: PPGL / PPGI / BGL / GC
Yield strength: 550 MPA (Max.)
Length of profile sheet: No limit
Total connected power required: 20 KW
Coil Width range: 900 mm to 1500 mm
Coil Thickness range: 0.25 mm to 0.80 mm
Coil weight (Allowed on Decoiler): Up To 10000 Kg.
Production line speed
(Without Cutting):
0 to20MPM
Production line speed
(With Cutting):
18 to 20 MPM (as per job length)
2 Ton Per Hour /Material Thickness 0.50
Automation level in performance P.L.C. controlled length
Accuracy level length: ±2 M.M.
  • HG
  • HG
  • HG
